TECHNICAL DATA Design pressure CE/PED Vacuum to 100 bars ASME Vacuum to 47 bars Design temperature Carbon steel Shell -29 - 538°C Stainless steel Shell -160 - 538°C Standard design pressure (g) / temperature HS ASME/PED 10 bar / -29 - 300°C US ASME/PED 25 bar / -29 - 300°C SS ASME/PED 40 bar / -29 - 300°C. Maximum heat transfer surface AlfaDisc 50 22 m2 (235 sq.ft.) AlfaDisc 100 66 m2 (706 sq.ft.) AlfaDisc 150 162 m2 (1733 sq.ft.) STANDARD MATERIALS Shell Material Mild steel, Epoxy painted or stainless steel Cover Material Mild steel, Epoxy painted or stainless steel Nozzles Stainless steel and Titanium Could be combined with carbon steel flanges Plate material 316L & Titanium STANDARD CONNECTIONS Sizes mm (inch) Plateside Shellside AlfaDisc50 50 (2”) 50-150 (2”- 6”) AlfaDisc100 100 (4”) 100-300 (4”-12”) AlfaDisc150 150 (6”) 150-400 (6”-16”) Pressure ratings CE/PED PN16, 25&40 ASME ASME cl. 150, 300 & 600 H D Lmin Lmax AD50 686(27) 305(12) 483(19) 1219(48) AD100 1117(44) 559(22) 635(25) 1448(57) AD150 2032(80) 863(34) 965(38) 1880(74) PCT00064EN 0708 How to contact Alfa Laval Up-to-date Alfa Laval contact details for all countries are always available on our website at www.alfalaval.com. Alfa Laval reserves the right to change specifications without prior notification. PED ASME AlfaDisc – PED/ASME approval pressure/temperature graph PS (bar/PSI) -196 (-321) 75 (167) 125 (257) 175 (347) 225 (437) 250 (482) 350 (662) 550 (1022) 450 (842) 20 (290) 18 (261) 16 (232) 14 (203) 12 (174) ºC (ºF) TS Measurements mm (inch) Particulars required for quotation - Flow rates or heat load - Temperature program - Physical properties of liquids in question (if not water) - Desired working pressure - Maximum permitted pressure drop - Available steam pressure H L D Under development
