SW150-SW250.pub table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.00pt "Arial", sans-serif; } .font1 { font:5.00pt "Arial", sans-serif; } .font2 { font:7.00pt "Arial", sans-serif; } .font3 { font:9.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:13.00pt "Arial", sans-serif; } .font6 { font:15.00pt "Arial", sans-serif; } .font7 { font:14.00pt "Arial Black", sans-serif; } .font8 { font:12.00pt "Tahoma", sans-serif; } .font9 { font:7.00pt "Times New Roman", serif; } International û SU80 Single Pole Single Throw Normally Open (Part of the SU Séries) Application Interrupted Uninterrupted Thermal Current Rating (Ith) r 150A 200A À Intermittent Current Rating: 30% Duty r 275A 365A À 40% Duty r 235A 315A À 50% Duty r 210A 280A À 60% Duty r 190A 260A À 70% Duty r 180A 240A À Rated Fault Current Breaking Capacity (Icn) 5ms Time Constant: SU80 r 800A at 48V D.C. À SU80B r 800A at 80V D.C. À Rated Fault Current Breaking Capacity (Icn) Resistive Load*: SU80 r 300A at 60V D.C. À SU80B r 300A at 96V D.C. À Maximum Recommended Contact Voltages (Ue): SU80 r 48V D.C. 60V D.C. À SU80B r 96V D.C. À Typical Voltage Drop per pole across New Contacts at 100A r < 40mV f Mechanical M.T.B.F r >3 x 106 À Coil Voltage Available (Us) (Rectifier board required for A.C.) r From 6 to 240V A.C./D.C. À Coil Power Dissipation: Very Intermittently Rated Types r 20 - 30 Watts À Intermittently Rated types r 15 - 20 Watts À Prolonged Rated Types r 13 - 15 Watts a Continuously Rated Types r 7 - 13 Watts À Maximum Pull-In Voltage (Coil at 20° C) Guideline: Very Intermittently Rated types (Max 25% Duty Cycle) r 60% Us À Intermittently Rated types (Max 70% Duty Cycle) r 60% Us A Prolonged Operation (Max 90% Duty Cycle) r 60% Us À Continuously Rated Types (100% Duty Cycle) r 66% Us À Drop-Out Voltage Range r 10 - 25% À Typical Pull-In Time r 20ms À Typical Drop-Out Time (N/O Contacts to Open): Without Suppression r 5ms À With Diode Suppression r 50ms À With Diode and Resistor (Subject to resistance value) r 8 - 20ms À Typical Contact Bounce Period r 3ms À Operating Ambient Temperature r - 40°C to + 60°C À Guideline Contactor Weight: SU80 r 350 gms À With Auxiliary r + 20 gms À With Blowouts r + 50 gms À Auxiliary Details Auxiliary Thermal Current Rating r 5A À Auxiliary Contact Switching Capacities (Resistive Load): SU80A SU80C 5A at 24V D.C. À ^ 2A at 48V D.C. ^ ^ 0.5A at 240V D.C. À Advised Connection Sizes for Maximum Continuous Current Copper busbar ^ 97mm2 [0.15inch2] 129mm2 [0.20inch2] A Cable ^Rated suitable for Application^ Key: = Interrupted = Uninterrupted Note: Where applicable values shown are at 20°C * In accordance with UL508 The SU80 is an up-rated version of the SW80 Contactor designed for Interrupted and Uninterrupted loads. It is suitable for switching Resistive, Capacitive and Inductive loads. Typical applications include, but are not limited to, electric motors, hydraulic power packs, winches, speed controllers, UPS and Power Distribution Systems. Interrupted current - opening and closing on load with fréquent switching (results in increased contact resistance). Uninterrupted current - no or infrequent load switching requirements (maintains a lower contact resistance). The SU80 features single pole double breaking main contacts with silver alloy tips, which are weld résistant, hard wearing and have excellent conductivity. Economical in price they compare favourably with sealed automotive style solenoid switches which cannot be serviced or inspected for contact wear. Mounting can be vertical or horizontal, when vertical the M8 contact studs should point upwards. Dimensions in mm [inches] 39 [1.54] 6.3mm [0.25] SPADE TERMINALS FOR COIL CONNECTIONS M8 MAIN TERMINALS TO BE TIGHTENED WITHIN RANGE 8-9.5Nm OPTIONAL MICROSWITCH AUXILIARY CONTACT WITH 6.3mm [0.25] SPADE TERMINALS CAN BE FITTED HERE SU80C (V3 Auxiliary Contacts) 23 [0.921 M4 MOUNTING HOLES (4 OFF PER SIDE) CLOSED CONTACT HOUSING CAN BE SUPPLIED TO PREVENT INGRESS OF DUST ETC. 12.7 [0.501 6.3mm [0.25] SPADE TERMINALS SU80 Available Options General Auxiliary Contacts (SU80A) o Auxiliary Contacts - V3 (SU80C) o Magnetic Blowouts* o Magnetic Blowouts - High Powered* o Armature Cap o Mounting Brackets (see SU Series Catalogue) o Magnetic Latching (Not fail safe)* o Closed Contact Housing o Environmentally Protected IP66 o EE Type (Steel Shroud) o Contacts Large Tips o Textured Tips o Silver Plating X Coil AC Rectifier Board (Fitted) o Coil Suppression* o Flying Leads o Manual Override Operation o M4 Stud Terminals X M5 Terminal Board o Vacuum Impregnation o Key: Optional o Standard • Not Available X * Connections become polarity sensitive s) d n o c e (S SU80 Contactor Performance 1 1 1 1 Figures are for guideline purposes only \ \ 0 E l- Current (Amperes) Contact Performance Key: — Interrupted Current Connection Diagrams SU80A SU80C Uninterrupted Current AUXILIARY CONTACT N'O N'C N'C N'O AUXILIARY CONTACT NC2 A +0 Performance data provided should be used as a guide only. Some de-rating or variation from figures may be necessary according to application. Thermal current ratings stated are dependant upon the size of conductor being used For further technical advice email: technical@albrightinternational.com Albright reserve the right to change data without prior notice Albright Internbtiona l Ltd,Evingar Trading Estate, Ardglen Road, Whitchurch, Hampshirn, RG28 7BB, UK, Tel: +44 (0)iaX6 893060, Fax: +44 (0)1256 893562 Dedicated Sales Tel: +44 (0)1256 890030, Fax: +44 (0)125n 89na43, E-moil: oales@albrightinterhational.com ortechnical@albright.nternationei.com Web Site: www.albrightinternational.com v4-08-11 Copyright © 2011 Albright International LTD SU80
