Air Logic is a manufacturer of various pneumatic accessories. Ideal for instrumentation, medicaland industrial applications. The pneumatic accessories include Check Valves, Orifice Restrictors, Needle Valves, miniature Inline Filters, Orifice Filter combinations and Preset Flow Controls. Inline Filters The Inline Filters are designed for compressed airsystems to remove most contaminate particles. Threemodels are available. An inline filter with barbs for 1/16 or 1/8Ԕ I.D. tubing, a filter encased in a 10-32 UNF housingwith barbs for 1/16 or 1/8Ԕ I.D. tubing, or a filter withfemale 10-32 UNF...

Needle Valves The Needle Valves are ideal for instrumentation andindustrial applications. The fine angle of the needle allows forthe precise control of flow. The Needle Valves are adjustablefrom 0 to the equivalent flow of a 0.025 diameter orifice. Theflow is restricted in both directions. The various featuresinclude panel mounting, a knurled adjustment knob, stainlesssteel pins. Buna-N, Viton or EDPM OԒrings are available. The body is available in various materials, Phosphor Bronze,Nylon or Polypropylene. Publication 9300 > Check Valves Publication 9300 The Check Valves permit flow in one...

Bulkhead Connector The Standard Bulkhead Connectors are precisionmolded of nylon and are available in two models, theReducing and Straight Bulkhead Connector. The connector joins 1/16, 1/8Ԕ or .170 I.D. flexible tubing and are panelmounted. Publication 9600 Multiple Bulkhead Connectors Publication 9600 F-3100 Series F-3103 Series F-3120 Series F-3120 Series The Multiple Bulkhead Connectors are precisionmolded of polysulfone and are available in two models, 10tube connector and 32 tube connector. The 10 tube con- nector seals with a press fit and can be panel mounted. The 32 tube connector...

Barbed Unions, Elbows, Tees & Crosses The barbed Unions, Elbows, Tees and Crosses areprecision molded of nylon and join 1/16 I.D. or 1/8Ԕ I.D.flexible tubing together. The celcon Plastic Tee joins 1/16 I.D. flexible tubing together. Publication 9600 Swivel FittingsF-3140 Series F-3150 SeriesF-3250 SeriesF-3350 Series F-4150 Series The Swivel Fittings (Patent #4,946,204) are availablein three models, the Straight Swivel, the Swivel Elbow andthe Swivel Tee. The swivels are available with barbs for 1/16Ԕ, 3/32 or 1/8Ԕ I.D. flexible tubing. The swivels areavailable with 10-32 UNF threads,...

Subminiature Pressure Switches The Switches are adjustable 0.5-100 PSI with a maxi-mum of 100 PSI supply. The switches have four mountingstyles that are available: Flush Mount, Panel Mount, 1/8-27 NPTMount and Manifold Mount.15 AMPSwitches are standard, 0.1 to 25 AMPandSolid State Switches are available. For a low differencebetween the ԓON and ԓOFF pressure, a Low DifferentialPressure Switch is available. Publication 9000. Suminiature Vacuum Switches F-5100 SeriesStandardF-5300 SeriesLow DifferentialF-5500 SeriesSolid State V-5100 Series StandardV-5300 SeriesLow DifferentialV-5500...

Miniature Pressure Switches The Switches are available with preset and adjustablepressure settings. The F-4100-50 is preset at 5 H20 and theF-4100-90 is preset at 15Ԕ H20. The F-4100-85W isadjustable 8 to 85 H20. The F-4100-100 and the F-4100-200are adjustable 0.5-15 PSI. Publication 9500 Miniature Vacuum Switches Publication 9000 The Switches are available with preset and adjustablevacuum settings. The V-4100-0.7 is preset at .7Ԕ Hg, the V-4100-1 is preset at 1 Hg, and the V-4100-4 is adjustable from 1.5 to 4Ԕ Hg. Maximum 30 Hg. Pressure Pilot 3-Way Valve F-4100 Series F-5700, F-5800...

Test Point Indicator The Test Point Indicator is a simple low pressure on-off indicator which actuates at 4 H2O. The indicator maybe permanently installed in fluid systems for observing logic sequencing in routine operation. Publication 9400 Diaphragm AmplifierF-2913 Series F-4014 Series F-4103 Series The Diaphragm Amplifiers are miniature pneumatic 3-way interface devices for piloting valves and small cylinders. Input signals of 3 to 8 inches of water will control output pressures up to 35 PSI. Publication 9400 Publication 9400 Diaphragm Comparator The Diaphragm Comparator is a versatile...

Vacuum Generator The Vacuum Generator is designed to produce a lowflow vacuum using the venturi principle. The vacuum gener-ator converts compressed air to a vacuum consuming 4.9 SCFH with a 13 PSI supply.When air is allowed to flow through the generator, thehigh velocity of the air passing through the center port drawsa vacuum through the side ports. Two red vinyl caps are pro- vided to cap the unused output port. Subminiature size. Publication 9400 Sensor Venturi V-4417 Series F-4417 SeriesF-4417-40 Series Publication 9400 The Sensor Venturi gives definite onӔ or definite offӔsignal with...

Fluidic NOR Logic Elements Abasic element from which all logic circuits can beconstructed. Plugs into F-3802-60 Manifold Card. FluidicTransverse Impact Modulator principle has no moving parts, half-millisecond response, high recovery and fan out. Publication 9500 F-3702 Series F-4102 Series F-3705 Series Manifold Card Publication 9500 Plug-in mounting and supply manifold for six NORLogic Elements. Numbered connecting terminals for 1/16 I.D. tubing. Packaged with two F-3802-5 Manifold Card Plugs for unused element sockets. F-3802-60 Series Atwo-input analog fluidic pressure comparison...

Key to ratings: RRecommendedLRLimited Recommendation (manyapplications possible depending on stress level).NRNot Recommended*No data Miscellaneous Commercial Products ClobberӔ Acidic Drain Cleaner, 100%LR CopperbriteӔ Copper Cleaner, 100%R Duckseal Sealant,Ӕ 100%LR Oils:ASTM Oil #1, 100%R ASTM Oil #2, 100%R ASTM Oil #3, 100%R ASTM Oil #10, 100%RSilicones:SilasticӔ 140, 100%R RTV-88 (GE), 100%LR RTV-106 (GE)R RTV-109 (GE)RZephiranӔ Disinfectant, 100%R Pipe Seal Compounds Loc-TiteӔ AV 100%NR Loc-TiteӔ B, 100%NR Loc-TiteӔ E, 100%NR MastersӔ Metallic, 100%R PermatexӔ #2, 100%R TeflonӔ TF-15,...
