FLOW CONTROLS

Function code:

"C" Controlled Flow Out "V" Controlled Flow In

"B" Bidirectional Flow

8952

FEMALE NPTF FLOW CONTROL (CONTROLLED FLOW OUT)


		0
			lilil
	88952 32 32	10/32	10/32	.157 (4)	.394 (10)	.945 (24)	.315 (8)	c
	88952 02 02	1/8	1/8	.217 (5.5)	.650 (16.5)	1.181 (30.5)	.551 (14)	c
	88952 04 04	1/4	1/4	.276 (7)	.866 (22)	1.417 (36)	.669 (17)	c
	88952 06 06	3/8	3/8	.295 (7.5)	1.035 (26.3)	1.614 (41)	.787 (20)	c

88962

FEMALE ■

PTF FLOW CONTROL (CONTROLLED FLOW IN)


	Part No.	F NPTF	A SWIFT				^9
	88962 32 32	10/32	10/32	.157 (4)	.394 (10)	.945 (24)	.315 (8)	V
	88962 02 02	1/8	1/8	.217 (5.5)	.650 (16.5)	1.181 (30.5)	.551 (14)	V
	88962 04 04	1/4	1/4	.276 (7)	.866 (22)	1.417 (36)	.669 (17)	V
	88962 06 06	3/8	3/8	.295 (7.5)	1.035 (26.3)	1.614 (41)	.787 (20)	V

88972

§MFF/Fnr FEMALE NPTF NEEDLE VALVE (BIDIRECTIONAL FLOW)


	Part No.		A SWIFT				CH	FUNCTION
	88972 32 32	10/32	10/32	.157 (4)	.394 (10)	.945 (24)	.315 (8)	B
	88972 02 02	1/8	1/8	.217 (5.5)	.650 (16.5)	1.181 (30.5)	.551 (14)	B
	88972 04 04	1/4	1/4	.276 (7)	.866 (22)	1.417 (36)	.669 (17)	B
	88972 06 06	3/8	3/8	.295 (7.5)	1.035 (26.3)	1.614 (41)	.787 (20)	B

41

320 Premier Court • Suite 224 • Franklin, TN • 37067 • 615-771-6650 • www.alphafittings.com
