Ident-Nr. 991517 06505 11/08 Your specialist distributor AFRISO-EURO-INDEX GmbH • Lindenstraße 20 • DE-74363 Güglingen/Württ. • Germany Phone +49 (0) 71 35/1 02-0 • Fax +49 (0) 71 35/1 02-1 47 • info@afriso.de • www.afriso.de NO-Measurement Measuring range: 0 ... 2.000 ppm Resolution: 1 ppm Accuracy: ± 5 ppm of meas. value Memory Micro-SD-card (Option: std. commercial up to max. 4 GB) Housing (Protective Sleeve) Mineral fibre plastic (slot plastic with magnet) Power Supply NiMH rechargeable battery 6V/2Ah, external mains adaptor and charger Temperature Plug connector system for NiCr-Ni thermoelements (Type K) Connections Draught/Pressure: 7 mm diam Gas: 8 mm diam Date Communication USB-interface via cable Wireless infra-red printer interface Bluetooth (optional) Approvals Acc. to BlmSchV and KUO as well as EN 50379-2 Weight (instrument only) approx. 400 g Scope of Delivery EUROLYZER ST, incl. of calibration protocol, mains adaptor, flue gas probe, condensate filter cartridge, ambient air sensor, connector set for gas fittings, protective sleeve with magnet, aluminium instrument case Type Pt.-No. EUROLYZER ST O2, CO, (differential) temperature 69332 EUROLYZER ST O2, CO, (differential) temperature, draught 69333 EUROLYZER ST O2, CO, (differential) temperature, draught, (differential) pressure 69334 EUROLYZER ST O2, CO, NO, (differential) temperature, draught 69251 EUROLYZER ST O2, CO, NO, (differential) temperature, draught, (differential) pressure 69252 Options Pt.-No. Package memory function 69303 Bluetooth interface 69236 Printer 69480 Technical Specifications Measured values, depending on equipment O2, CO/H2, NO, Flue gas temperature, combustion air temperature, draught, pressure Calculated values, depending on equipment CO undiluted, NOx, Lambda, CO2, efficiency (Eta), temperature difference, pressure difference Eta-BW (for combustion systems), flue gas losses (qA), dewpoint Input possibilities, depending on equipment Sutt figure, oil derivatives, customer No., boiler temperature Measuring ranges Flue gas temperature (incl. differential pressure measurement) Measuring range: 0 °C/+1.000 °C Resolution: 1 °C Accuracy: ± 1 °C + 1 digit (up to 300 °C) ± 1% of meas. value (above 300 °C) Thermoelement: NiCr-Ni (Type K) External wall or air temperature Measuring range: -20 °C/+200 °C Resolution: 0,1 °C Accuracy: ± 3 °C + 1 digit (-20,0 to 0,0 °C) ± 1 °C + 1 digit (-0,1 to +200,0 °C) Thermoelement: NiCr-Ni (Typ K) Draught/Differential pressure Measuring range: ± 50 hPa (draught)/± 130 hPa (diff.-press.) Accuracy: ± 2 Pa (up to ± 2 hPa) ± 1% of meas. value (up to ± 50 hPa) ± 1,5% meas. value (above ± 50 hPa) Resolution: 1 Pa (= 0,01 hPa) O2-Measurement Measuring range: 0 ... 21 vol.-% Resolution: 0,1 vol.-% Accuracy: ± 0,2 vol.-% of meas. value CO2-Determination Indicating range: 0 ... CO2 max. Resolution: 0,1 vol.-% Accuracy: ± 0,2 Vol.-% CO-Measurement Measuring range: 0 ... 5.000 ppm (nom.)/0 ... 9.999 (max.) Resolution: 1 ppm Accuracy: ± 5 ppm (up to 50 ppm) ± 5% of meas. value (above 50 ppm)
