DriPak® 2000 Nominal Size Pockets Rated Airflow Gross Media *Rated Initial Resistance (in. w.g.) (Inches) Per Capacity (CFM) By Area Average Efficiency: (W x H x D) Filter *Rated Filter Face Velocity: (sq. ft.) MERV 15 MERV 14 MERV 12 MERV 8 375 FPM 500 FPM 625 FPM 90-95% 80-85% 60-65% 40-45% Recommended final resistance is 1.0" w.g. for all models. 24 x 24 x 36 9 2500 117 .53 .48 .44 -- 24 x 24 x 36 8 2000 104 .31 .29 .27 -- 24 x 24 x 36 7 2000 91 .34 .30 .29 -- 24 x 24 x 36 6 2000 78 .35 .31 .29 -- 24 x 20 x 36 6 1675 66 .37 .31 .31 -- 20 x 24 x 36 6 2075 78 .44 .41 .35 -- 20 x 24 x 36 5 1675 65 .37 .31 .31 -- 20 x 20 x 36 5 1400 58 .37 .31 .31 -- 12 x 24 x 36 4 1000 1250 52 .41 .37 .35 -- 12 x 24 x 36 3 1000 39 .35 .31 .29 -- 24 x 24 x 30 10 2000 107 .42 .34 .34 -- 24 x 24 x 30 8 2000 85 .38 .32 .29 -- 24 x 24 x 30 6 2000 64 .43 .36 .31 -- 24 x 20 x 30 6 1675 54 .46 .37 .31 -- 20 x 24 x 30 6 1675 64 .40 .36 .30 -- 20 x 24 x 30 5 1675 53 .46 .37 .34 -- 20 x 20 x 30 6 1400 57 .41 .32 .29 -- 12 x 24 x 30 5 1000 53 .42 .34 .34 -- 12 x 24 x 30 4 1000 43 .38 .32 .29 -- 12 x 24 x 30 3 1000 32 .43 .36 .31 -- 24 x 24 x 21 10 2000 75 .55 .41 .38 -- 24 x 24 x 21 8 2000 60 .54 .42 .33 -- 24 x 24 x 21 6 1500 45 .48 .37 .27 -- 24 x 20 x 21 8 1675 53 .50 .37 .34 -- 24 x 20 x 21 6 1250 40 .38 .28 .21 -- 20 x 24 x 21 6 1675 45 .58 .47 .35 -- 20 x 24 x 21 5 1250 37 .49 .38 .31 -- 20 x 20 x 21 6 1400 38 .52 .35 .30 -- 20 x 20 x 21 5 1050 33 .43 .26 .22 -- 12 x 24 x 21 5 1000 37 .55 .41 .38 -- 12 x 24 x 21 4 1000 30 .54 .42 .33 -- 12 x 24 x 21 3 750 22 .48 .37 .27 -- 24 x 24 x 19 6 2500 42 .32 24 x 20 x 19 6 2075 37 -- -- -- .32 20 x 24 x 19 5 2075 35 -- -- -- .32 20 x 20 x 19 5 1750 30 -- -- -- .32 12 x 24 x 19 3 1250 21 -- -- -- .32 24 x 24 x 15 10 1500 53 .49 .37 .31 -- 24 x 24 x 15 8 2000 43 -- -- -- .25 24 x 24 x 15 6 1500 32 .68 .50 .34 -- 24 x 20 x 15 6 1675 29 -- -- -- .25 20 x 24 x 15 5 1675 28 -- -- -- .25 20 x 20 x 15 5 1400 24 -- -- -- .25 12 x 24 x 15 5 750 27 .49 .37 .31 -- 12 x 24 x 15 3 750 16 .68 .50 .34 -- 12 x 24 x 15 3 1000 17 -- -- -- .25 24 x 24 x 12 6 2000 27 -- -- -- .27 24 x 20 x 12 6 1675 24 -- -- -- .27 20 x 25 x 12 6 1750 27 -- -- -- .27 20 x 24 x 12 5 1675 22 -- -- -- .27 20 x 20 x 12 5 1400 19 -- -- -- .27 16 x 25 x 12 5 1400 23 -- -- -- .27 16 x 20 x 12 4 1100 15 -- -- -- .27 12 x 24 x 12 3 1000 13 -- -- -- .27 *All performance data is based on the ASHRAE 52.2 and ASHRAE 52.1 test methods. Performance tolerances conform to Section 7.4 of ARI Standard 850-93. Gaskets and Loops — Gaskets, for side access systems or other applications which require gaskets, and pocket support loops are available on all DriPak 2000 filters. Classifications — DriPak 2000 filters are classified UL Class 1 and Class 2. Testing was performed according to UL Standard 900 and CAN 4-S111. Temperature Limits — DriPak 2000 filters, operating with fan on, are designed for a continuous operating temperature of 200¢ª F or 93¢ª C. AAF has a policy of continuous product research and improvement and reserves the right to change design and specifications without notice. 10300 Ormsby Park Place Suite 600 Louisville, Kentucky 40223-6169 www.aafintl.com Customer Service 888.AAF.2003 Fax 888.223.6500 ISO Certified 9001:2000 © 2008 AAF International The USGBC Member logo is a trademark owned by the AFP-1-114J OCT '08 VI 5M U.S. Green Building Council and is used by permission.
