Product Information

Bearing Temperature sensors

WDB

BRAIME

WDB

Bearing Temperature Sensors

ATEX-Approved for for dust-explosive environments Zones 20, 21 & 22

APPLICATION

Bearing Temperature Sensors with thermistors type PTC, NTC, or PT100 (PTC 80°C stocked as standard - other temperatures available on request)

FEATURES

.- Easy installation; sensors screw into existing bearing grease nipple

.- Bearing sensors can be used with the control modules T400 ELITE or

WATCHDOG ELITE & T500 ELITE, all ATEX-certified . Standard supply: 12 Vdc or 24 Vdc

. Certified for ATEXZone 20 Ex II 1DT125°C IP65 -ZONE 20 & CSA Class 2, Div. 1, Groups E, F & G

WDB24V3CA steel body Conduit entry

WDB14V3A bronze body Cable entry

ATEX-Approved Ex II 1D T100°C -IP 65-ZONE 20

CLASS 2 Div. 1 Groups E, F & G

Installation of bearing temperature sensor

Detailed specification, wiring diagrams and installation/operating instructions available immediately upon request.

Please refer to instruction manual for correct installation . Information subject to change or correction. July 2007.

4B BRAIME INDUSTRIAL ELEVATOR COMPONENTS LTD Hunslet Road, Leeds, LS10 1JZ, UK Tel:+44 (0) 113 246 1800 Fax: :+44 (0) 113 243 5021 4b-uk@go4b.com
