APPLICATION
Alarm indication panel with external alarm horn.For use with
level indicators, hazard controls and
industrial limit switch devices.The X400 ‘Elite’ uses an electronic microprocessor control unit, which works in conjunction withvarious sensors to monitor up to 8 alarm zones. Alarm input voltages can be in the range of 24-240V
AC or DC and zones are isolated from each other and from the control unit. A test push button on the
lid of the control unit (magnetically actuated) provides for full system verification. Alarm and status
LEDs provide quick location of the alarm condition and voltage free relay contacts provide separate
alarm and shutdown control. An alarm mute push button is provided on the lid of the control unit
(magnetically actuated) and additional connections are provided for an external alarm mute push
button. An option for RS485 comms. allows remote monitoring by PLC or PC.
FEATURES
•Multiple alarm inputs from different sensors•Wide range inputs - Accepts mixed alarm input voltages 24-240V AC/DC•Status lights - Control unit LEDs indicate individual alarms, and control unit alarm and power status•Alarm mute - Alarm mute activation with automatic reactivation on new alarm•Test feature - Includes controlled test facility, activated externally•Outputs - Voltage free isolated relay contacts and RS485 serial comms. option
•CSA/NRTL/ATEX pending •Dust hazard approved
OPTIONS
•Pt. No. RS485EM - RS485 Serial Comms. Module•Pt. No. AH1V1/2/3/4 - External Alarm Horn
PART NUMBERS / VOLTAGE
X4002V345FC -24-240V AC, 12-24V DC
WEIGHT
1.5Kg/Each Detailed specification, wiring diagrams and installation/operating instructions available immediately upon request.
