AUTO-SET MK4RADIO FREQUENCY LEVEL INDICATOR AND REMOTE AUTOSET

UNIVERSAL APPLICATION

A point level indicator for silos and bins, suitable for almost all liquids and granular materials. Standard probes up to 10 metres. Remote/high heat options up to 250ËšC.The auto-set measures the ‘dielectric property’ (electrical resistance) of the material in the bin andcompares this to air. This enables the unit to sense the presence or absence of material touching the probe and to provide a switched output signal for control purposes.

FEATURES

•Power shield ignores material ‘build-up’•Multi voltage - 110/240V AC and 24V DC•Output - One voltage free relay contact (SPDT)•Push button automatic calibration•Adjustable timer - 0 to 128 seconds•User adjustable relay state - Signal on material arriving or leaving •Switchable high/low fail safe•Remote Autoset available as option•Dust proof and watertight - IP65 •User selectable high/low level interlink •Hazardous area approved - CSA/NRTL/ATEX Zone 20

PROBE CHOICES

ATSPMINI - Solid stainless steel probe ATSP11 - 200mm Solid stainless steel probe ATSP12 - 1M Solid stainless steel probe ATSP13 - 2M Solid stainless steel probe ATWP11 - 10M Stainless steel wire probe
ATSPMINI ATSP11 ATSP12 ATSP13 ATWP11

ACCESSORIES

85mm38mm • SMP - Side mounting plate. 1
1 /
4 ” NPT•
200mm ADP - Adaptor 1
1 /
4 ” NPT ~ 1” BSP
16mm 880mm

OPTIONS

•DGR - Digiset remote•Extended power shield unit available
1880mm

PART NUMBERS / MOUNTING THREAD

ATS6VOA Control Unit -1” BSP- M20 Conduit entry
10m max. ATS7VOFC Control Unit -1
1 /
3 4 ” NPT - /
4 ” NPT Conduit entry

VOLTAGE

110/240V AC, 50/60Hz 24V DC,

WEIGHT

Control Unit-0.9Kg/eachSolid 200mm Stainless steel probe-0.3Kg/eachSolid 1M Stainless steel probe-1.5Kg/eachSolid 2M Stainless steel probe-2.0Kg/eachWire 10M Stainless steel probe-1.3Kg/each Detailed specification, wiring diagrams and installation/operating instructions available immediately upon request.
