| | | BOLT 'N' GO | | |
| | | Flight Installation and Chain Assembly Made Easy! Drop Forged Chain | | |
| | | T | |
| | | |
| | | |
| | | Features • Easy and simple assembly on site or in the shop • Precise calculated flight bending forces • Guaranteed and reliable pin attachment • Condensed storage and shipping costs • Forged chain and round link chain compatible • Plastic flight option (high density polyethylene or nylon) • Steel flight option (drop forged chain only) | | |
| | | Link and flight assembly are made easy by using a standard bolt and nut with a high strength hollow pin. There are no circlips to become loose and there is no intricate assembly. There is no welding required on the flights, no need to remove chain form the manufacturer of conveyor for installation, and no issues with strength. Just bolt the links and the flights together. It's easy, simple and reliable! U.S. Patent #7,080,728 Other Patents Pending | | |
| | | |
| | | www.go4b.com | | |
| | | |
| | | |
| | | |
| | | r rrtm | | |
| | | |
| | | Forged Chain with Bolt 'n' Go Flights | | |
| | | |
| | | J ^Drop Forged Chain Dimensions | | |
| | | |
| | | Bolt 'n' Go System is available on 3 Drop Forged Chain sizes | | |
| | | |
| | | No. | | Description | | 102 N-A Link | | 142 N-A Link | | 142 H-A Link | | |
| | | | |
| | | |
| | | | | | | | | | | | | 1 | Drop Forged Chain Link | GB0102BNA | GB0142BNA | GB0142BHA | | | | 2 | Attachable Plastic Flight (Max. Width 600mm) | GB0102BFP (HDP) GB0102BFN (Nylon) (400mm) | GB0142BFP (HDP) GB0142BFN (Nylon) | GB0142BFP (HDP) GB0142BFN (Nylon) | | | | 3 | Attachable Steel Flight (Max. Width 600mm) | GB0102BF (400mm) | GB0142BF (600mm) | GB0142BF (600mm) | | | | 4 | Reinforcement Plate (For Flights Over 400mm) | Not Required | GB0142BBF | GB0142BBF | | | | 5 | Bolt 'n' Go Assembly Kits (Pins included) | GBOI02NPAC - No Flights GB0I02NPAF - Flights | GB0142NPAC - No Flights GB0142NPAF - Flights | GB0142HPAC - No Flights GB0142HPAF - Flights | | | | | | | | | | | | |
| | | |
| | | Bolt 'n' Go - Drop Forged Chain Link | | |
| | | |
| | | A | | Weight | | Min. Breaking Load | | Case Hardness | | Case Depth | | Core Hardness | | |
| | | Lnk | | P | | H | | | T | | |
| | | |
| | | |
| | | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | 102 N-A | 102 mm | 36 mm | 28 mm | 7.62 mm | 0.38 Kg | 150 Kn | Rockwell | 0.5 mm | Rockwell | | | | | 4.02 in | 1.42 in | 1.10 in | 0.30 in | 0.80 Lbs | 33,000 Lbs | C59/64 | 0.02 in | C40 | | | | 142 N-A | 142 mm | 50 mm | 42 mm | 11 mm | 1.08 Kg | 300 Kn | Rockwell | 0.7 mm | Rockwell | | | | | 5.59 in | 1.97 in | 1.65 in | 0.43 in | 2.38 Lbs | 67,500 Lbs | C59/64 | 0.03 in | C40 | | | | 142 H-A | 142 mm | 50 mm | 62 mm | 16.5 mm | 1.76 Kg | 450 Kn | Rockwell | 0.7 mm | Rockwell | | | | | 5.59 in | 1.97 in | 2.44 in | 0.65 in | 3.88 Lbs | 101,000 Lbs | C59/64 | 0.03 in | C40 | | | | | | | | | | | | | | | | | |
| | | |
| | | 5 | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
