LEVEL INDICATORS

Rotary level indicators for point level indication of bulk granular materials in bins and silos.These electro-mechanical rotary units are simple to use and reliable. The Roto-Safe incorporatesa sensor specifications to detect that the paddle is rotating for failsafe monitoring. The

TiltSwitchRoto-Level Indicators

RLI is the original basiclow cost rotary level indicator with quality Swiss-made motor and gearbox. A simple high position point levelindicator with housing and tilt “POD.” Cable length is adjustable to 5m. TST TiltSwitch Roto-Safe RLI RLI Simple tilt level indicator with relayoutput and timer Failsafe rotary level indicator General purpose rotary levelindicator Low-cost rotary level indicator(shown with TMP, paddle andextension rod)

TiltSwitchRoto-Level Indicators TST TiltSwitch Roto-Safe RLI

Features Features Features

Accessoriesfor Roto-Level Indicators

•Control unit housing•Changeover relay contact•Internal timer •Adjustable cable length•Chain attachment loops• •Failsafe paddle rotation detection•Glass-fibre reinforced nylonhousing•Vertical extensions to 5m areavailable•Internal sensitivity adjustment•Adjustable timer•Automatic power shut-off•Dust hazard approved •Glass-fibre reinforced nylonhousing•Vertical extensions to 5m areavailable•Automatic power shut-off •Supplier of limit switch contact output•Heavy-duty version available 1 5º tilt angle operation

Rotary LevelPaddles

Complete range of stainlesssteel paddles for Roto-Level Indicators.

Style Style Style

Control unit with 1
1 /
4 -inch mounting thread andexternal tilt “POD” Rotary level indicator with Rotary level indicator with 1
1 /
4 -inch NPT mounting thread 1
1 /
4 -inch NPT mounting thread

Supply voltage Supply voltage Supply voltage

1 20/240 VAC 24 VDC (universal supply) 1 20/240 VAC 24 VDC (universal supply) 1 1 20 VAC - must specify240 VAC - must specify 2 VDC - must specify24 VDC - must specify

Mounting Plate

Output Output Output

Powder-coated mild steelmounting plates with 1 1 set of voltage-free changeover relay contacts 1 set of voltage-free changeover relay contacts 1 set of voltage-free changeover relay contacts
1 / 4 -inch NPT half or full coupling. Use with Autoset, Tiltswitch,Roto-Level Indicators andBinswitches with adapters. (Also available in stainless steel.)

Approvals Approvals Approvals

•Europe - ATEX •Europe - ATEX•USA, Canada - CSA –

Applications Applications Applications

High or intermediate point level indicator forfree flowing bulk granular materials. Material point level indication inbins, silos, hoppers and other vessels where failsafe detection is required, or for dust hazard areas. Material point level indication in bins, silos, hoppers and other vessels.

For more detailed product information, please visit: www.go4b.com
