LEVEL INDICATORS

Autoset

Autoset Remote

A user friendly, reliable point level Indicator for bulk granular solids, powders and liquids. Digital display, push-button calibration and material build-up compensator make this unit the elite point level detection

A user friendly, reliable point level Indicator for bulk granular solids or powders where there is high vibration and/or temperature involved. Remote electronic display/control unit allows for remote calibration/set-up away from vibration or heat.

ATWP11 —

ATSP13 T-

ATSP12 e

ATSP11 —

ATSP10 —

A selection of screw-on stainless steel probes to suit your application.


ATS6 RF capacitance point level indicator	♦ ATS6 with Extended Power Shield RF capacitance point level indicator for thick-walled silos	ATS6 Flush Probe RF capacitance heavy-duty plugswitch
Autoset
ATS6 Features • Push button calibration • Digital display • Internal timer • Automatic material build-up compensator • Attachable SS probes	ATS6 with Extended Power Shield Features • Push button calibration • Digital display • Internal timer • Automatic material build-up compensator, 12 or 16 inches long • Attachable SS probes	ATS6 Flush Probe Features • Push button calibration • Digital display • Internal timer • Automatic material build-up compensator • No moving parts
Style 1 inch BSP	Style 1 inch BSP	Style 1 00mm diameter probe with integral mount
Supply voltage 120/240 VAC 24 VDC (universal supply)	Supply voltage 120/240 VAC 24 VDC (universal supply)	Supply voltage 120/240 VAC 24 VDC (universal supply)
Output 1 set of voltage-free changeover professional relay contacts	Output 1 set of voltage-free changeover relay contacts	Output 1 set of voltage-free changeover relay contacts
Approvals • Europe - ATEX • USA, Canada - CSA	Approvals • Europe - ATEX • USA, Canada - CSA	Approvals • Europe - ATEX • USA, Canada - CSA
Applications Material point level indication in silos, bins and other vessels. Plug condition in chutes and discharges.	Applications Material point level indication in thick-walled concrete silos.	Applications Plugswitch for manufacturers of conveyors and bucket lifts.

Autoset Professional remote control

Remote control unit with digital display and calibration push buttons

Autoset Remote Probe

Polyprop probe - 120°C

PEEK probe - 250° C Ceramic probe - 600° C

Autoset Remote


	Autoset Remote Features • No moving parts • No electronic components • Automatic material build-up compensator • Attachable SS probes • High temperature available	Autoset Remote Control Features • Push button calibration • Digital display • Internal timer • DIN rail mountable
	Style 1 inch BSP	Style DIN rail mountable enclosure
	Supply voltage From control unit	Supply voltage 1 20/240 VAC 24 VDC (universal supply)
	Output To control unit	Output 1 set of voltage-free changeover relay contacts
	Approvals • Europe - ATEX	Approvals • Europe - ATEX
	Applications Material point level indication in surge bins, vibratory feeders and high temperature processes.	Applications Material point level indication in surge bins, vibratory suppliers of feeders and high temperature processes.
