SPEED SWITCHES

Speedswitch

A solid state unit with no moving parts, the M800 is maintenance free. The unit operates using an inductive sensing device and requires no contact with the monitored machine. The M800 is calibrated to the machine's normal RPM. If the shaft speed falls by 10%, the M800 will alarm, and by 20% it will shut the machine down.

Slipswitch

Stopswitch

The Stopswitch is a straightforward shaft speed monitoring center. The 2-wire technology saves you time and makes installation hassle-free. If the shaft stops rotating, the Stopswitch will provide an output. It requires no calibration to operate and is a great tool for process control, motion verification and stopped shaft indication.

User friendly and easy to Install, the Slipswitch Is a simple shaft speed monitoring device. Available in 2-wire and 5-wire models, the Slipswitch is self-calibrating and provides a 20% underspeed output to protect against dangerous belt slip and underspeed conditions.



w
M800 Speedswitch Intelligent underspeed switch with three outputs	M300 Slipswitch 2-wire Intelligent underspeed switch with 2-wire output	M3005 Slipswitch 5-wire Intelligent underspeed switch with one output	M100 Stopswitch Stopped motion professional monitor
Speedswitch	Slipswitch		Stopswitch
M800 Speedswitch Features • Totally sealed • Auto calibration • 1/2-inch conduit entry with 2m cable • Status LED's	M300 Slipswitch 2-wire Features • Totally sealed • Auto calibration • 2-wire device • 5m cable • Status LED's	M3005 Slipswitch 5-wire Features • Totally sealed • Auto calibration • 3 or 5-wire connection • 5m cable • Status LED's	M100 Stopswitch Features • Small 18mm diameter • Totally sealed • 5m cable • Status LED's
Style DIN (40mm x 40mm)	Style 30mm cylindrical	Style 30mm cylindrical	Style 1 8mm cylindrical
Supply voltage 120 VAC - must specify 220 VAC - must specify 24 VDC - must specify	Supply voltage 24 to 240 VAC 12/24 to 240 VDC (universal supply)	Supply voltage 24 to 240 VAC 1 2/24 to 240 VDC (universal supply)	Supply voltage 24 to 240 VAC 1 2/24 to 240 VDC (universal supply)
Output 1 x 10% underspeed professional relay 1 x 20% underspeed relay 1 x NPN transistor pulse (All 3 outputs in 1 unit)	Output 1 x 20% underspeed Triac with maximum load of 200mA	Output 1 x 20% underspeed relay	Output Stopped motion signal Triac with maximum load of 200mA
Approvals • USA, Canada - CSA	Approvals • Europe - ATEX • USA, Canada - CSA • Worldwide - lECEx	Approvals • Europe - ATEX • USA, Canada - CSA • Worldwide - lECEx	Approvals • Europe - ATEX • USA, Canada - CSA
Applications Conveyors, bucket elevators, any speed sensitive shaft for automatic underspeed detection with 1 0% alarm and 20% shutdown.	Applications Conveyors, professional bucket industrial elevators, any speed sensitive shaft for automatic 20% underspeed detection.	Applications Conveyors, bucket elevators, any speed sensitive shaft for automatic 20% underspeed detection.	Applications Process control. Provides a signal when the shaft has stopped rotating.

All 4B speed sensors are compatible ,7* ^J- M q, ^ £f I

with the Whirligig universal shaft /

m to-

manufacturers of sensor mount.

www.go4b.com See page 6.
