WDA sensor detects movingferrous material and is designed for
use with bucket elevators to detect
industrial buckets, for measurement of speedand alignment. It is a non contactingextended range sensor to detect
targets which are up to 100mm from
the sensor. It can also detect ferrousbolts where non ferrous buckets arebeing used. The sensor is used in
conjunction with a SUPPLIER OF PLC or with a
Watchdog, T500 Elite or A400 Elitecontrol unit. Touchswitch is an electro-mechanical limitswitch with no moving
parts, that detects the misalignment ofboth pulleys and belts in conveyors andbucket industrial elevators. The sensor detects
the lateral force of the belt or pulley and
activates a voltage free professional relay contact.This relay contact can be used toactivate an alarm or shutdown the
machine. Thesensors are normallyinstalled in pairs on opposite sidesof the belt/pulley. BAPWDA High PowerSensorTouchswitch CBS2
The BAP detects moving ferrousmaterial and is designed for use withbucket elevators to detect buckets,
for measurement of speed and
alignment. It can also detect ferrousbolts where non ferrous buckets arebeing used. The sensor is used in
conjunction with a PLC or with a
Watchdog, T500 Elite or A400 Elitecontrol unit.
The The CBS2 is an electro-mechanicalsystem to detect the misalignmentof abelt conveyor. Two outputs are given at
15 and 30 degrees which can be used
as alarm and stop signals respectively.Works in conjunction with a CBS2V0Acontrol unit. The suppliers of sensors are normally
installed in pairs, one on either side of
the belt, and up to 4 sensors per CBScontrol unit.
The BAP WDA Touchswitch CBS2 Belt alignment/speed monitor Belt alignment/speed and chainbreak monitor Belt/pulley misalignment sensor Conveyor belt supplier alignment monitor Belt Misalignment Monitors BAP2 1 V34AI WDA3V34CAI TS 1 V4AI CBS2
Features Features Features Features
•
Manufacturer of magnetic sensor unaffected bymaterial build up•Continuously monitors the movingelevator, with visual indication by an
LED• •Long range magnetic sensorunaffected by material build up•Continuously monitors the movingelevator, with visual indication by
an LED•25- •Hardened, annealed stainless steelface•External test knob for quick andsimple sensor/system testing•Not affected by dust or materialbuild up•Visual indication by an LED •Two outputs at 1 5 & 30 degrees foralarm and shutdown•Nylon and stainless steel rollersavailable•Self assembly adjustable supportsystem 1 2-50mm range depending on thesize of the target, easily adjusted
from the sensor itself or from the
optional independent control unit 1 00mm range depending on thesize of the target, easily adjusted
from the sensor itself or from the
optional independent control unit•Mounting bracket included•Stainless steel construction•High temperature version available
Supply voltage Supply voltage Supply voltage Supply voltage
1 2/24 VDC 24 VDC 24 VDC 11 0-240 VAC
Approvals Approvals Approvals Approvals
•Europe - ATEX•Worldwide - IECEx •Europe - ATEX
•USA, Canada - CSA•Worldwide - IECEx •Europe - ATEX
•USA, Canada - CSA (available onrequest)•Worldwide - IECEx •Europe - ATEX
Applications Applications Applications Applications
Belt alignment and
speed sensor manufacturers Belt alignment and speed sensor.Chain break monitor Belt/pulley misalignment on elevatorsand conveyors Conveyor belt alignment monitor
For more detailed product information, please visit: www.go4b.com
