X400 Elite – Alarmswitch is amicroprocessor based control unitwhich is able to accept contactstylesignals in 8 separate zones. Alarm and status Industrial leds provide quick location ofthe alarm. A singlelocal and optionalremote alarm mute push button acknowledges any alarm condition.

HAZARD MONITORING SYSTEMS

B400 Elite is a microprocessorbased control unit which uses manufacturers of sensors to detect belt misalignment by pressure (Touchswitch) from one ortwo industrial elevators/industrial conveyors. The unit isable to provide an alarm and automatic shutdown of the elevator/conveyor when a belt misalignment conditionis detected.The

TemperatureMonitoring Belt Alignment Monitoring Alarm Monitoring

The T400 Elite - Hotswitch is amicroprocessor controlled temperaturemonitor, which works in conjunction withPTC temperature sensors specifications to monitor up to 48 bearings and canprovide an alarm and automaticshutdown when a high bearing temperature condition is detected. The A400 Elite is a microprocessorbased control unit which uses highpower magnetic detectors that detect moving metallic industrial buckets or bolts from either one or two bucket lifts.The unit is able to provide an alarmand automatic shutdown of the elevator when a belt misalignment/ underspeed condition is detected.The Bearing temperature monitorBucket elevator belt alignmentmonitoring systemConveyor or bucket elevator beltalignment industrial monitoring system Centralized alarm monitoring system

Belt Alignment MonitoringAlarm MonitoringTemperature Monitoring T400 Elite - Hotswitch A400 Elite B400 Elite X400 Alarmswitch

Features Features Features Features

•Monitors 8 zones with up to 6 PTCsensors in each zone (48 total)•Status LEDs provide quick locationof the hot bearing condition •Sensors are positively mountedgrease through •Alarm mute •RS485 serial communication (optional)•SUPPLIER OF PLC board with 8 contact outputs(optional) •Uses up to 4 magnetic (reluctance)alignment sensors •Monitors alignment of belts in twoseparate elevators or top and bottom alignment in one elevator •Includes 2 separate alarm and 2separate stop relays •Simple, reliable, consistent. Fullyfunctionaltest via push button onfront panel •RS485 serial communication (optional) •Uses up to 4 touch or capacitivealignment sensors •Monitors alignment of belts in twoseparate machines or top and bottom alignment in one machine •Includes 2 separate alarm and 2separate stop relays •Simple, reliable, consistent. Fullyfunctionaltest via push button onfront panel for general testing•RS485 serial communication (optional) •Monitors up to 8 zones•Multiple alarm inputs from differentsensors•LED alarm indication and power status•Alarm mute – local and remote •Test feature•RS485 serial communication (optional)•PLC board (optional)

Sensor options Sensor options Sensor options Sensor options

•WDB Series: bearing temperature•Extensive range of sensors availablefrom 50 - •WDA Series: motion alignment•BAP Series: motion alignment •Touchswitch: force activated•Binswitch: capacitance proxy (openbelt conveyors) •Autoset Series: level indicator•Roto-Level Series: level indicator •Binswitch: level and plug indicator•M Series Speedswitch: speed•Touchswitch: belt alignment 1 00°C

Input supply voltage Input supply voltage Input supply voltage Input supply voltage

1 00 to 240 VAC24 VDC (universal supply) 1 00 to 240 VAC24 VDC (universal supply) 1 00 to 240 VAC24 VDC (universal supply) 1 00 to 240 VAC24 VDC (universal supply)

Sensor supply Sensor supply Sensor supply Sensor supply

1 2 VDC 24 VDC 24 VDC 24 VDC

Approvals Approvals Approvals Approvals

•Europe - ATEX •USA, Canada - CSA•Worldwide - IECEx •Europe - ATEX •USA, Canada - CSA •Worldwide - IECEx •Europe - ATEX •USA, Canada - CSA•Worldwide - IECEx •Europe - ATEX •USA, Canada - CSA•Worldwide - IECEx

H x W x D H x W x D H x W x D H x W x D

246 x 1 88 x 1 02mm 246 x 1 88 x 1 02mm 246 x 1 88 x 1 02mm 246 x 1 88 x 1 02mm

Applications Applications Applications Applications

Bucket elevators and conveyors Belt bucket elevators Belt bucket elevators and conveyors Bucket elevators, conveyors, silos and bins
www.go4b.com 3
