LEVEL INDICATORS

Accessories for LevelIndicators

Binswitch

A popular range of capacitance proxy level/plug industrial detectors fordetecting dry bulk granular material level in bins, silos, hoppers and chutes. This simple but robust point level indicator has no moving parts, is self-contained with all potted electronics, and canbe used in areas of high vibration. The units are simple to installon the sides or tops of steel bins/hoppers and are small enough to be used as plug detectors in discharge chutes. Serial network system for continuousmonitoring of supplier of bearing temperature, belt misalignment, and more. Combined belt speed, belt alignment,bearing temperature, pulley alignment and plugged condition monitoring device. page 2 page 2page 3

X400 Elite AlarmSwitch

Industrial alarm panel with 8 multi-voltage inputs and alarm indication LED’s for use with any type of level indicator. Binswitch Binswitch capacitiveproximity manufacturers of sensor Capacitance proxy sensor withprogrammable features Binswitch Capacitance sensor shown withadjustable level kit

Rotary Level Paddles Binswitch

Complete range of stainlesssteel paddles for Roto-Level Indicators.

ProgrammableBinswitch 5-Wire StandardBinswitch 2-Wire Binswitch

Features Features Features

•User adjustable sensitivity•LED status professional lights•Programmable internal timer •Failsafe relay adjustable forhigh or low level•Fully potted electronics•2m cable •User adjustable sensitivity•LED status lights•Fully potted electronics •5m cable•5-wire device•Relay contact output •User adjustable sensitivity•LED status lights•Fully potted electronics •5m cable•2-wire device

Mounting Plate

Powder-coated mild steel mounting plates with 1 1 / 4 -inch NPT or 1 inch BSP, half or fullcoupling. Use with Autoset, Tiltswitch, Roto-Level Indicators and Binswitches withadapters. (Also available in stainless steel.)

BAS3 Abrasion Shield

Style Style Style

Polyethylene abrasion shield for ATEX Binswitch 30mm cylindrical 30mm cylindrical 30mm cylindrical

Supply voltage Supply voltage Supply voltage

24 to 240 VAC 24 to 240 VAC 24 to 240 VAC 1 2 to 240 VDC (universal supply) 1 2 to 240 VDC (universal supply) 1 2 to 240 VDC (universal supply)

BMPA Mount

Urethane compression professional fitting mount for use with Binswitch. 1 1 / 4 -inch NPT external thread.

Output Output Output

1 set of voltage-freechangeover relay contacts 1 set of voltage-freechangeover relay contacts 2-wire output with maximum load of 200mA

Conduit Adapter

Approvals Approvals Approvals

Anodized aluminum 30mm to 3 / 4 -inchNPT adapter for use with the Binswitch. •USA, Canada - CSA •Europe - ATEX•USA, Canada - CSA •Worldwide - IECEx •Europe - ATEX•USA, Canada - CSA•Worldwide - IECEx

Applications Applications Applications

Dry free flowing material level detection in bins, silos, hoppers and chutes. Dry free flowing materiallevel detection in bins, silos, hoppers and chutes. Dry free flowing materiallevel detection in bins, silos, hoppers and chutes.

Gland Mount

Plastic gland mount for use with the Binswitch.

BTAS Teflon AbrasionShield

Teflon Abrasion Shield screw-on endcap for ATEX Binswitch. www.go4b.com 9
