Product Information
AUTO-SET MK4
BRAIME
Radio-Frequency Level indicator
ATEX-approved for zones 20,21 et 22
DESCRIPTION
The AUTO-SET MK4 is a radio-frequency level indicator which allows to detect low, medium and high levels on almost all liquid and granular materials, such as powders, grain, sugar, etc...
The AUTOSET MK4 has a display and can be set up using simple push­buttons and switches to save the settings.
It has a power shield function that enables it to automatically compensate for material build-up on the probe.
CHARACTERISTICS
- Power shield to minimise the affect of material adhering
- Available with 5 probes up to 10 meters.
- Display unit -IP 65
- Supply 110/230 VAC / 24DC.
- Output contact
- Set-up by push-button.
- Timer delay 0 to 128 seconds variable
- Button fail-safe high/low level
- Sensitivity adjustable by the user
ATS6V0A
ATEX-approved
Ex II 1D T100°C-IP 65-ZONE 20
OPTIONS
- Stainless steel version version for the food and pharmaceutical industries:
ATS6V0A
- ATEX-extended version: ATS6V0A-300
- Remote version for applications on vibrating elements or high temperatures: ATSR1
- Extra flat / compact version: ATS6V0A-FP
Detailed specification, wiring diagrams and installation/operating instructions available immediately upon request.
Please refer to instruction manual for correct installation. Information subject to change or correction. July 2007.
4B BRAIME INDUSTRIAL ELEVATOR COMPONENTS LTD Hunslet Road, Leeds, LS10 1JZ, UK Tel:+44 (0) 113 246 1800 Fax: :+44 (0) 113 243 5021 4b-uk@go4b.com
