Product Information
4BJ07 4BJ12
BRAIME
JUNCTION BOXES
Certified for dust-explosive environments Zones 21 & 22
ATEX-approved
Ex II 2D T125°C-IP 66-ZONE 21
Technical Features: Certification : Ex II 2D T 125C. Protection : IP 66.
Material of the housing : High-resistance polyamide Nominal tension : Up to 690V Dimensions in mm (LxHxD) : 141x87x111
Two types of models :
REF : 4BJ07
-Cable entries : 1x M25 for 0 8-17mm.
1x M25 for 2x04.5-7mm
+1 stopper plug
2 M25 bolts
-Terminal SPRINGS : 7x 2.5mm2+ 6 earth terminals
1x M25 for 2x0 4,5-7mm
Please refer to instruction manual for correct installation . Information subject to change or correction. July 2007.
4B BRAIME ELEVATOR COMPONENTS LTD Hunslet Road, Leeds, LS10 1JZ, UK Tel:+44 (0) 113 246 1800 Fax: :+44 (0) 113 243 5021 4b-uk@go4b.com
www.go4b.com
